SHURE SLXD24DA/B58-M55 ไมค์ลอย2ตัว +++ ไมค์ลอย มือถือคู่ แบบดิจิตอล 24 บิต คลื่นความถี่ 694-703 MHz และ 748-758 MHz เอไอ-ไพศาล

FEATURES

• Transparent 24-bit digital audio
• Extended 20 Hz to 20 kHz frequency range (microphone dependent)
• 120 dB dynamic range
• Digital predictive switching diversity
• 44 MHz tuning bandwidth (region dependent)
• 32 available channels per frequency band (region dependent)
• Up to 10 compatible systems per 6MHz TV band; 12 systems per 8 MHz        band
• Easy pairing of transmitters and receivers over scan and IR sync
• Rugged metal construction

SPECIFICATIONS

Dimensions (H × W × D) 1.65 × 15.5 × 5.98 in (42 × 393 × 152 mm)

Weight 3.2 lb (1451 g) without antennas

Housing Galvanized Steel

Power Requirements 15 VDC @ 600 mA Supplied by external power      supply (tip positive)

RF INPUT

Spurious Rejection >75 dB Typical

Connector Type BNC

Impedance 50 Ω


AUDIO OUTPUT

Gain Adjustment Range

–18 to +42 dB in 1 dB steps

Configuration
1/4″ (6.35 mm): Balanced (Tip=audio +, Ring=audio –, Sleeve=ground)
XLR: Balanced (1=ground, 2=audio +, 3=audio –)

Impedance
1/4″ (6.35 mm): 1.3 kΩ (670 Ω Unbalanced)
XLR (line): 400 Ω (200 Ω Unbalanced)
XLR (mic): 150 Ω

Full Scale Output
1/4″ (6.35 mm): +15 dB differentially (+9 dBV single)
XLR (LINE setting): +15 dBV
XLR (MIC setting): –15 dBV

Mic/Line Switch
30 dB pad

Phantom Power Protection
1/4″ (6.35 mm): Yes
XLR: Yes

NETWORKING

Network Interface
Single Port Ethernet 10/100 Mbps

Network Addressing Capability
DHCP or Manual IP address

Maximum Cable Length
100 m (328 ft)
